NEURO SWING Carbon

The NEURO SWING Carbon system ankle joint provides dynamic straightening and improves gait and stability. In dorsiflexion, the motion is controlled via an integrated, reinforced dorsiflexion assist or against the resistance of the anterior spring unit. In plantar flexion, the movement is guided for a controlled, dynamic lowering of the foot and for the control of the tibial progression with a knee-flexing effect in loading response. Thanks to the durable, carbon fibre-reinforced joint case it is dirt- and water-resistant.

The system joint provides a dynamic and adjustable dorsiflexion and plantar flexion stop. The stops are set by the spring units. The orthosis’ alignment is adjustable. The range of motion and spring force can be adjusted in dorsiflexion as well as in plantar flexion by exchanging the spring units of the dirt- and water-resistant joint case. The system joint adjustments do not influence each other. Therefore, they can be changed separately and independently.
